Specification
3003-H24 aluminum foil has several properties that provide unique advantages for container forming
1.Better strength and formability
2. Excellent resistance to corrosion
3. High temperature resistance
4. Uniform thickness & good surface quality
A consistent rolling process provides consistent thickness with a smooth surface and without pinholes makes it necessary for food containers to be leak-proof.
Details include:
| Alloy |
8011, 1235 |
| Temper |
O (Soft) |
| Thickness |
8–25 microns |
| Width |
200mm–1600mm |
| Roll Core ID |
76mm (3 inch) or 152mm (6 inch) |
| Surface |
One side bright, one side matte |
| MOQ |
3 tons per size |
| Packaging |
Standard export wooden case |
| Customization |
Thickness, width, logo, and packaging can be customized |
| Application |
Household kitchen foil rolls, catering foil, baking foil, wrapping foil |
How to Select The Right Specifications For Food Container Jumbo Roll Aluminum FoilWhen selecting jumbo roll aluminum foil for food containers, the manufacturer needs to consider the below key technical specifications:
1. Thickness Selection
The thickness affects the strength and weight. Some common thicknesses are:
Light duty containers: 0.03-0.05 mm.
Medium duty containers: 0.05-0.08 mm.
Heavy duty containers: 0.08-0.12 mm.
2. Width Length
The width will depend on the Model and size of the container. The common width ranges from 200 mm to 1500 mm. The wider the roll, the more productive the operation.
3. Mechanical Properties
The tensile strength and elongation properties must match the stamping depth necessary. 3003-H24 will suit as it maintains mechanical properties in the initial material without alteration.
4. Surface Treatment
Options include uncoated, lubricated, embossed or color-coated foil. Food-grade lubricants help facilitate the stamping step.
5. Core ID & Roll Weight
Common IDs of the cores we have: 76 mm / 152 mm
The more the roll weighs, the less time is wasted on the stamping line.
Factors Which Affect Your Choice of Specifications
Design of the container and its depth
Stiffness required and load-bearing capacity
Heating / sterilization
Regulatory compliance of food contact materials
FAQ: Frequently Asked Questions About 3003-H24 Aluminum Foil (10+)1. How does the foil 3003-H24 compare to foil 8011-O?3003-H24 foil has more strength, retains better formability for deep-drawn containers.
2. Is 3003-H24 aluminum foil safe to bake with in the oven?Yes. It is dimensionally stable at peak temperatures and will not deform or melt.
3. What is the minimum order quantity (MOQ)?MOQs vary based on width but typically for jumbo rolls you are looking at 3–5 tons per size.
4. What surface treatment options are there?Plain, lubed, embossed, coated – the standard options.
5. Is the food-grade lubrication safe?Yes, it complies with international food contact standards.
6. What is the normal lead-time?Usually between 20–35 days; it depends on the quantity.
7. What is the roll-width that can be provided?Yes, roll-width typically ranges from 200–1500 mm.
8. What testing reports can be provided?We can provide reports for chemical composition, mechanical properties, pinhole density, and migration testing.
9. What are the packaging options?Fumigation-free wooden cases, moisture-proof, steel strapping.
10. How long can containers made from the 3003-H24 foil be stored?If stored dry and clean they can be stored for years.
